Flow Cytometry
Flow Cytometry detects and measures the physical and chemical characteristics of cellular and particle parameters at the single-cell level. They can then be isolated by a fluorescence-activated cell sorter for further downstream applications.
Offers conventional flow cytometry analysis with the added capability to record full spectral analysis of up to 48 parameters. This also allows for the ‘unmixing’ of autofluorescent cells.
Supports medical, biological, pharmaceutical and environmental applications.
Technical specifications
- 5 Lasers, 48 parameters
- UV laser 355nm – 10 parameters
- Violet laser 405nm – 14 parameters
- Blue Laser 488nm – 9 parameters
- Yellow/Green Laser 561nm – 9 Parameters
- Red Laser 633nm – 6 parameters
- Ability to perform conventional flow cytometry or switch to full spectrum analysis with no filter limitations
Measures the relative size, internal complexity and fluorescence intensity of a single cell or particle.
Supports medical, biological, pharmaceutical and environmental applications.
Technical specifications
- 5 lasers, 18 parameters
- Blue 488nm laser: FITC, PerCp
- Red 633nm laser: APC, APC – Alexa 700, APC-Cy7
- Violet 405nm laser: BV421, BV510, BV605, BV650, BV711, BV786
- Yellow/Green 561nm laser: PE, PE-CF594, PE-Cy7
- UV 355nm laser: BUV395, BUV496, BUV737, BUV805
- High throughput sampler to run 96 well plates
Allows the isolation of defined cell or particle subset(s) from heterogenous mixtures. Cells can be sorted according to size, granularity, surface markers and DNA content. They can also be sorted in a sterile environment enabling the recovered cells to be cultured and used for further downstream applications.
Supports medical, biological, pharmaceutical and environmental applications.
Technical specifications
- 4 lasers, 16 parameters
- Blue 488nm laser: FITC, PerCp
- Red 633nm laser: APC, APC – Alexa 700, APC-Cy7
- Violet 405nm laser: BV421, BV510, BV605, BV650, BV711, BV786
- Yellow/Green 561nm laser: PE, PE-Cy5, PE-Cy5.5, PE-CF594, PE-Cy7
- Sorting of up to 4 different populations into 1.5ml, 5ml and 15ml tubes, 96 well plates and microscope slides
- Single cell and index sorting
Allows the isolation of defined cell or particle subset(s) from heterogenous mixtures. Cells can be sorted according to size, granularity, surface markers and DNA content. They can also be sorted in a sterile environment enabling the recovered cells to be cultured and used for further downstream applications.
Supports medical, biological, pharmaceutical and environmental applications.
Technical specifications
- 3 lasers, 9 parameters
- Blue 488nm laser: FITC, PE, PerCp, PECy-7, PE-Texas Red
- Red 633nm laser: APC, APC-Cy7
- Violet 405nm laser: BV421, BV510
- Sorting of up to 4 different populations into 1.5ml, 5ml and 15ml tubes, 96 well plates and microscope slides
- Single cell and index sorting
Measures the relative size, internal complexity and fluorescence intensity of a single cell or particle.
Supports immune-phenotyping, clinical diagnostics, cell cycle analysis, cytoxicity studies, proliferation studies, apoptosis and cell death, algal quantification, microalgae, nuclear DNA content, aquatic organisms, protein characterisation, relative size determination and analysis of nano particles.
Technical specifications
- 3 lasers, 8 parameters
- Blue 488nm laser: FITC, PE, PerCp, PECy-7
- Red 633nm laser: APC, APC-Cy7
- Violet 405nm laser: BV421, BV510
- High throughput sampler to run 96 well plates
Measures the relative size, internal complexity and fluorescence intensity of a single cell or particle.
Supports immune-phenotyping, clinical diagnostics, cell cycle analysis, cytoxicity studies, proliferation studies, apoptosis and cell death, algal quantification, microalgae, nuclear DNA content, aquatic organisms, protein characterisation, relative size determination and analysis of nano particles.
Supports medical, biological, pharmaceutical and environmental applications.
Technical specifications
- 3 lasers, 8 parameters
- Blue 488nm laser: FITC,PE, PerCp, PECy-7
- Red 633nm laser: APC, APC-Cy7
- Violet 405nm laser: BV421, BV510
Measures the relative size, internal complexity and fluorescence intensity of a single cell or particle.
Supports immune-phenotyping, clinical diagnostics, cell cycle analysis, cytoxicity studies, proliferation studies, apoptosis and cell death, algal quantification, microalgae, nuclear DNA content, aquatic organisms, protein characterisation, relative size determination and analysis of nano particles.
Technical specifications
- 2 lasers, 6 parameters
- Blue 488nm laser: FITC, PE, PerCp, PECy-7
- Red 633nm laser: APC, APC-Cy7
